We can provide customized products and project products according to specific requirements. Please feel free to contact us if you need.
| Model | Rated voltage | Rated power | Rated current | Rated speed | Rated torque | Noload current | Noload speed | Work duty | Insulation resistance | Brush life | Electrical strength | Insulation class | Protection grade |
Ambient temperature
|
Noise |
Ratio
|
Gearbox rated torque
|
Efficiency
|
|
ZDSJ-24310GU-18S-N |
24VDC | 310W | 16A | 1800rpm±10% | 1.64N.m | ≤4A | 2300rpm±10% |
S2-30min |
>20MΩ | 1000h | 660V/S | B | IP00 |
-10℃~+40℃
|
＜60dB (L=100cm)
|
10:1 |
14.8N.m
|
90% |
1.The red lead is connected to the positive and the black lead is connected to the negative. Seen from the output shaft, motor turns clockwise. When the lead position is reversed, the motor turns in the opposite direction;
2.The brush life is 1000 hours;
3.Lead wire length: 650mm±20, model: UL1015, spec: 10AWG.
