We can provide customized products and project products according to specific requirements. Please feel free to contact us if you need.
|
Model |
Output Power |
Voltage |
Frequency |
Rated Current |
Rated Torque |
Rated Speed |
Locked Rotor Torque |
Locked Rotor Current |
Insulation Grade |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF2-12H☐-15-S(TB) |
15 |
200 |
60 |
0.12 |
0.09 |
1550 |
0.16 |
0.30 |
F |
|
220 |
50 |
0.13 |
0.11 |
1350 |
0.26 |
0.35 |
|||
|
ZDF2-12H☐-15-S3(TB) |
380 |
50 |
0.08 |
0.11 |
1350 |
0.26 |
0.20 |
||
|
460 |
60 |
0.08 |
0.09 |
1680 |
0.30 |
0.22 |
|
Model |
Output Power |
Voltage |
Frequency |
Rated Current |
Rated Torque |
Rated Speed |
Locked Rotor Torque |
Locked Rotor Current |
Capacitor |
Insulation Grade |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
UF |
||
|
ZDF2-15A☐-15-C(TB) |
15 |
220 |
60 |
0.15 |
0.09 |
1680 |
0.08 |
0.33 |
1.20 |
F |
|
220 |
50 |
0.15 |
0.10 |
1380 |
0.08 |
0.35 |
||||
|
ZDF2-15A☐-15-A(TB) |
110 |
50 |
0.30 |
0.10 |
1380 |
0.08 |
0.68 |
5.00 |
||
|
110 |
60 |
0.34 |
0.09 |
1680 |
0.08 |
0.65 |
|
Power |
Aperture/Axis Diameter |
ReductionRatio |
Output Shaft Speed |
Output Shaft Torque |
Output Shaft Tolerance |
Output Shaft Tolerance |
|||
|
r/min |
N.m |
kgf.m |
Axial Force Load |
||||||
|
W |
mm |
i |
50Hz |
50Hz |
50Hz |
N |
kgf |
N |
kgf |
|
15 |
12/15 |
10 |
150 |
0.810 |
0.08 |
343 |
35 |
88 |
9 |
|
15 |
100 |
1.210 |
0.12 |
441 |
45 |
108 |
11 |
||
|
20 |
75.0 |
1.620 |
0.16 |
539 |
55 |
137 |
14 |
||
|
25 |
60.0 |
2.020 |
0.20 |
588 |
60 |
147 |
15 |
||
|
30 |
50.0 |
2.430 |
0.24 |
686 |
70 |
177 |
18 |
||
|
40 |
37.5 |
3.240 |
0.33 |
784 |
80 |
196 |
20 |
||
|
50 |
30.0 |
4.050 |
0.41 |
882 |
90 |
226 |
23 |
||
|
60 |
25.0 |
4.860 |
0.49 |
882 |
90 |
226 |
23 |
||
|
80 |
18.8 |
5.830 |
0.59 |
980 |
100 |
245 |
25 |
||
|
100 |
15.0 |
7.290 |
0.74 |
980 |
100 |
245 |
25 |
||
|
120 |
12.5 |
8.740 |
0.89 |
1080 |
110 |
275 |
28 |
||
|
160 |
9.40 |
11.66 |
1.18 |
1080 |
110 |
275 |
28 |
||
|
200 |
7.50 |
14.58 |
1.48 |
1080 |
110 |
275 |
28 |
||
|
240 |
6.30 |
17.49 |
1.78 |
1080 |
110 |
275 |
28 |
||
|
Model |
Output Power |
Voltage |
Frequency |
Rated Current |
Rated Torque |
Rated Speed |
Locked Rotor Torque |
Locked Rotor Current |
Insulation Grade |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF2-12H☐-25-S(TB) |
25 |
200 |
60 |
0.17 |
0.16 |
1450 |
0.22 |
0.36 |
F |
|
220 |
50 |
0.18 |
0.18 |
1300 |
0.34 |
0.43 |
|||
|
ZDF2-12H☐-25-S3(TB) |
380 |
50 |
0.11 |
0.18 |
1300 |
0.34 |
0.24 |
||
|
460 |
60 |
0.10 |
0.15 |
1650 |
0.36 |
0.27 |
|
Model |
Output Power |
Voltage |
Frequency |
Rated Current |
Rated Torque |
Rated Speed |
Locked Rotor Torque |
Locked Rotor Current |
Capacitor |
Insulation Grade |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
UF |
||
|
ZDF2-15A☐-25-C(TB) |
25 |
220 |
60 |
0.21 |
0.15 |
1620 |
0.09 |
0.46 |
1.50 |
F |
|
220 |
50 |
0.26 |
0.18 |
1320 |
0.09 |
0.52 |
||||
|
ZDF2-15A☐-25-A(TB) |
110 |
50 |
0.48 |
0.18 |
1320 |
0.09 |
0.93 |
6.00 |
||
|
110 |
60 |
0.43 |
0.15 |
1620 |
0.09 |
0.83 |
|
Power |
Aperture/Axis Diameter |
ReductionRatio |
Output Shaft Speed |
Output Shaft Torque |
Output Shaft Tolerance |
Output Shaft Tolerance |
|||
|
r/min |
N.m |
kgf.m |
Axial Force Load |
||||||
|
W |
mm |
i |
50Hz |
50Hz |
50Hz |
N |
kgf |
N |
kgf |
|
25 |
12/15 |
10 |
150 |
1.450 |
0.14 |
343 |
35 |
88 |
9 |
|
15 |
100 |
2.180 |
0.22 |
441 |
45 |
108 |
11 |
||
|
20 |
75.0 |
2.910 |
0.29 |
539 |
55 |
137 |
14 |
||
|
25 |
60.0 |
3.640 |
0.37 |
588 |
60 |
147 |
15 |
||
|
30 |
50.0 |
4.370 |
0.44 |
686 |
70 |
177 |
18 |
||
|
40 |
37.5 |
5.830 |
0.59 |
784 |
80 |
196 |
20 |
||
|
50 |
30.0 |
7.290 |
0.74 |
882 |
90 |
226 |
23 |
||
|
60 |
25.0 |
8.740 |
0.89 |
882 |
90 |
226 |
23 |
||
|
80 |
18.8 |
10.49 |
1.07 |
980 |
100 |
245 |
25 |
||
|
100 |
15.0 |
13.12 |
1.33 |
980 |
100 |
245 |
25 |
||
|
120 |
12.5 |
15.74 |
1.60 |
1080 |
110 |
275 |
28 |
||
|
160 |
9.40 |
20.99 |
2.14 |
1080 |
110 |
275 |
28 |
||
|
※ 200 |
7.50 |
25.50 |
2.60 |
1080 |
110 |
275 |
28 |
||
|
※ 240 |
6.30 |
25.50 |
2.60 |
1080 |
110 |
275 |
28 |
||
Note: The number for the torque limit model, please read this table.
